Allen-Bradley (Rockwell Automation)
1734-OB8 | digital output module; number of outputs: 8; output voltage range: 10…28.8 V DC; output topology: Sourcing
Manufacturer part number: 1734-OB8ESYS SKU: 1734OB8
Net unit price, VAT 0%
€145.12
VAT 25.5% and delivery are shown separately in the request summary.
Current availability
Current available stock: 2 pcs
- Minimum order
- 1 pcs
- Order increment
- 1 pcs
- Availability checked
- 1 Sept 2026, 08:35
Allen-Bradley (Rockwell Automation) 1734-OB8 is a digital output module. Key selection facts are number of outputs: 8; output voltage range: 10…28.8 V DC; output topology: Sourcing.
pcs
Information for product selection
Typical applications
- Use 1734-OB8 in machine actuator circuits when the design calls for number of outputs: 8.
- Choose 1734-OB8 for machine actuator circuits that must provide output voltage range: 10…28.8 V DC.
- Before ordering 1734-OB8, verify output topology: Sourcing against the machine actuator circuits design.
Key specifications
- Product type
- digital output module
- Number of outputs
- 8
- Output topology
- Sourcing
- Output voltage range
- 10…28.8 V DC
- Output current per channel
- 0.5 A
- Aggregate output current
- 2 A
Show additional verified specifications
- POINTBus current, maximum
- 75 mA @ 5 V DC
- Supply voltage
- 24 V DC
- Operating temperature
- -20…55 °C (-4…131 °F)
- I/O direction
- Output
- Signal technology
- Digital
- Target system
- POINT I/O
Lifecycle
- Status
- Active
Compatibility and related parts
Allen-Bradley POINT I/O 1734 system
System: Documented manufacturer system or product-family context; does not imply interchangeability with every member
Official manufacturer documents
- Allen-Bradley (Rockwell Automation) 1734-OB8 official product evidence (Technical document, en)Opens in a new window
- Official product cutsheet (Datasheet, en)Opens in a new window
- View Guidance (Datasheet, en)Opens in a new window
- POINT I/O Modules Selection Guide (1734-SG001) (Manual, en)Opens in a new window
