Allen-Bradley (Rockwell Automation)
1734-IE2V | analog input module; number of inputs: 2; input configuration: Single-ended voltage; input voltage ranges: -10…10 V; 0…10 V; 0…5 V; input resolution: 15 bit
Manufacturer part number: 1734-IE2VESYS SKU: 1734IE2V
Net unit price, VAT 0%
€225.37
VAT 25.5% and delivery are shown separately in the request summary.
Current availability
Current available stock: 0 pcs
- Minimum order
- 1 pcs
- Order increment
- 1 pcs
- Availability checked
- 1 Sept 2026, 08:35
Allen-Bradley (Rockwell Automation) 1734-IE2V is an analog input module. Key selection facts are number of inputs: 2; input configuration: Single-ended voltage; input voltage ranges: -10…10 V; 0…10 V; 0…5 V.
Direct ordering is unavailable for this item.
Send the part number and quantity to ESYS for availability or compatibility confirmation.
Information for product selection
Typical applications
- Use 1734-IE2V in sensor measurement channels when the design calls for number of inputs: 2.
- Choose 1734-IE2V for sensor measurement channels that must provide input configuration: Single-ended voltage.
- Before ordering 1734-IE2V, verify input voltage ranges: -10…10 V; 0…10 V; 0…5 V against the sensor measurement channels design.
Key specifications
- Product type
- analog input module
- Number of inputs
- 2
- Input configuration
- Single-ended voltage
- Input voltage ranges
- -10…10 V; 0…10 V; 0…5 V
- Input resolution
- 15 bit
- POINTBus current
- 75 mA @ 5 V DC
Show additional verified specifications
- Isolation voltage
- 50 V continuous
- Supply voltage
- 24 V DC
- Operating temperature
- -20…55 °C (-4…131 °F)
- I/O direction
- Input
- Signal technology
- Analog
- Target system
- POINT I/O
Lifecycle
- Status
- Active
Compatibility and related parts
Allen-Bradley POINT I/O 1734 system
System: Documented manufacturer system or product-family context; does not imply interchangeability with every member
Official manufacturer documents
- Allen-Bradley (Rockwell Automation) 1734-IE2V official product evidence (Technical document, en)Opens in a new window
- Official product cutsheet (Datasheet, en)Opens in a new window
- View Guidance (Datasheet, en)Opens in a new window
- POINT I/O Modules Selection Guide (1734-SG001) (Manual, en)Opens in a new window
