Siemens 6ES7135-4GB01-0AB0 ET 200S 2AO I ST analog output module
Manufacturer part number: 6ES7135-4GB01-0AB0ESYS SKU: 6ES7135-4GB01-0AB0
Net unit price, VAT 0%
€243.08
VAT 25.5% and delivery are shown separately in the request summary.
Current availability
Current available stock: 3 pcs
- Minimum order
- 1 pcs
- Order increment
- 1 pcs
- Availability checked
- 1 Sept 2026, 08:45
6ES7135-4GB01-0AB0 is a 15 mm SIMATIC ET 200S electronic module with two current outputs. Its ranges are ±20 mA at 13 bits plus sign and 4-20 mA at 13-bit resolution.
pcs
Information for product selection
Typical applications
- Controlling two analog current actuators in an ET 200S station
- Generating 4-20 mA or ±20 mA control signals
- Replacement of a 6ES7135-4GB01-0AB0 module
Key specifications
- Product system
- SIMATIC ET 200S
- Module type
- Analog current output module
- Analog output count
- 2
- Bipolar output range
- -20...+20 mA
- Unipolar output range
- 4...20 mA
- Resolution
- 13 bits; plus sign for the ±20 mA range
Show additional verified specifications
- Load voltage
- 24 V DC
- Maximum load impedance
- 500 Ω
- Maximum cycle time
- 1.5 ms
- Module width
- 15 mm
- Weight
- 40 g
Lifecycle
- Status
- Discontinued
Compatibility and related parts
SIMATIC ET 200S station with 24 V DC power module
System: Installs in a SIMATIC ET 200S station that supplies 24 V DC load voltage and uses a terminal module wired for the 2AO I ST module.
